Corning adsl vdsl pots splitter wiring diagram. Xdsl represents digital subscriber line which provides high bit rate digital information over tele phone subscriber lines. An adsl filter is normally a small plastic box with a short lead that plugs into your phone socket and two outputs one for your adsl modem and another for a. The universal dsl line module pots splitter is designed to be installed into the corning cable systems universal network interface device unid a 7600 type network interface device nid a 9600 type nid or a ptd type nid. The pots splitter is a passive device which allows both voice and. The term pots means plain old telephone service. Corning adsl vdsl pots splitter wiring diagram wiring diagram is a simplified agreeable pictorial representation of an electrical circuit.
The components of your dsl pots splitter may vary based upon the nid for which the kit was ordered. A typical loop configuration of cpe splitter installation is shown in figure 3. Corning cable systems xdsl pots dual line module is designed for use at the subscriber premis es. It shows the components of the circuit as simplified shapes and the faculty and signal connections amid the devices. Dsl pots splitter wiring diagram wiring diagram is a simplified enjoyable pictorial representation of an electrical circuit. Line dsl and pots.
It provides low pass filtering between the line port and pots port and a hpf high pass filter or all pass filter between line and dsl ports. The adsl pots splitter filter allows taking the full advantage of the 11mhz copper line frequency spectrum by stopping the telephone and adsl systems from interfering with each other.
