This manual applies to all insertion flow meters. For f 1100 f 1200 series only maximum temperature 180 f 82 c turbine insertion flow meter.
Onicon Flow Meter Power Supply Flow Measurement Free 30
Onicon f 1200 wiring diagram. F 1200 wiring diagram connect to power supply positive diagnostic signals orange bottom turbine frequency white top turbine frequency these signals are for diagnostic purposes connect to local display or btu meter red green black white orange 24 v frequency input ground top turbine bottom turbine onicon display or btu meter also available sel rst gpm power 463798 power. F 1299 stanls 1200 option stainless wetted metal f std instl1 install kit standard welded steel pipe. F 1200 series insertion dual turbine flow meters db 1201 flow display db 1201 displays are designed to convert a single onicon bidirectional insertion turbine or insertion electromagnetic flow meter into complete flow monitoring station. Onicon assumes no responsibilities for this product except as stated in the warranty. Standard features product literature ordering information related products simple to install. View online or download onicon f 1200 series owners manual.
All manuals are the most recent version of the onicon product manuals. Current manuals for all onicon products. 0 15 v peak pulse signal for onicon display or btu. To make sure that you are looking at the correct manual for your specific product please contact onicons sales office at 727 447 6140you may also e mail our sales office for assistance. The versatile display module can be located close to the flow meter or up to several hundred feet away. A user connections and internal wiring diagrams b installation hardware instructions.
Use as a local or remote display. You may also contact onicons technical service for system wiring diagrams that show the interconnection between the flow meter and any peripheral devices such as btu meter or display modules. Refer to onicons installation manuals for detailed wiring instructions. For use with serial numbers 115692 and later incorporated. Or btu meter refer to wiring diagram for peripheral device. Onicon f 1210 dual turbine insertion flow meter analog output.
Onicon f 1200 series pdf user manuals. The d 1201 is factory programmed and ready for use upon delivery.
