R1510l or other acuregulator wiring diagram bat alt field bus alt out o v r f d alt red yellow black 40a 100a red black blue diode is pipers e regulator is between the. Figures 1 and 2 are setup in the standard cessna wiring configuration where the voltage regulator alternator controller and the overvoltage sensor are separate.
R1510n
Zeftronics voltage regulator wiring diagram. Dgr6 ford pn. Increasing it when the system load increases and decreasing it when the load drops. Pg 14 wiring diagram bat alt field bus alt out acu f1 alt f2 40a 100a red white blue black diode is used on pipers 5a bat relay ov gfp trouble shooting light continued. Features part number r15100 rev a r15v00 r15v00 rev a. Low over voltage sensor indication improves safetywarns of low voltage ov condition remote voltage sensing improved voltage regulation. The built in ov sensor provides ov protection by turning off the ov relay inside the controller if the bus voltage exceeds 16v.
The voltage regulator with pulse width modulated pwm field control keeps the bus voltage constant by controlling the alternators field current. C611001 0101 0102 beech pn 33 380010 electrodelta pn vr 600 pftlamar pn. If the bus voltage exceeds the preset over voltage ov limit the ov normally closed relay will open up and. With the relay off the controller and the alternator turn off to protect sensitive avionics equipment and the battery. 110 zeftronics electrical charging systems solutions. Ibitayo 2003 zeftronics tovya group inc r15v0l pitpub.
Tsl 028 6 pl 150 120 331 363 mounting diagram height. Wiring diagram bat alt field bus alt out f1 alt f2 40a 100a acu r15300 r1530b 1a 4d 2b 3c 5a bat. The voltage regulator keeps the bus voltage constant by controlling the alternators. 110 by femi g. Off with the master switch on and no power to the acu red wire means that one power input device like switch circuit breaker or wiring is open. If the bus voltage exceeds the preset over voltage ov limit the ov relay which is normally closed will open.
Voltage regulation pulse width modulated. Expect the breaker to protect their non zeftronics regula tor. Reduced panel lights flicker. Reduced panel light flicker 022 2 pl. Figure 3 shows the system with the r15v00 rev a installed as a replacement for both units. Green with a sustained bus voltage of 20v to 256v means current is flowing from the acu but the alternator field or field wire to it is open.
R15100 separate ovs voltage regulator the r15100 replaces cessna pn.
